Overview
The MK-Y2105L is a weighing indicator built for accuracy, stability and effective noise rejection, so it conditions load-cell signals cleanly. Several weighing modes and set-point (fixed-value) control are available through a friendly operator interface, while the rich set of communication ports links the indicator to plant control systems for data exchange and automated management.
Key Features
- Standard output 0~5V / 0~10V (instruments with analog output function), compatible with common indicators
- Compact design for straightforward integration
Applications
Bench and process weighing with set-point control, plus integration into industrial automation, dosing and data-collection systems.
| Technical Parameters | |||
|---|---|---|---|
| Display | six-bit digital tube display | Keyboard | 5Pcs Button |
| Sensor excitation voltage | 5V DC | Serial port | Half-duplex RS485 |
| Standard IO Port configuration | 4~20mA (instruments with analog output) | Analog voltage output | 0~5V / 0~10V (instruments with analog output function) |
| A/D resolution | 2,000,000 | A/D Conversion rate | 6.25~100Hz |
| Instrument power supply | 16~24VDC or 220VAC | Dimension (L x W x D) | 90x42x130mm, panel 110x60mm |
| Operating temperature range | -20~60°C, relative humidity: 10%~85%, non-condensing | Storage temperature range | -40~80°C, relative humidity: 10%~85%, non-condensing |
Dimensions
| Model | + | |||
|---|---|---|---|---|
| TQ-Y2105L-N-F | 24VDC/220VACRS-485 | |||
| TQ-Y2105L-N-M | MODBUS RTU | |||
| TQ-Y2105L-A-F | 4-20mA/0-5V/0-10V | |||
| TQ-Y2105L-A-M | MODBUS RTU | |||
| TQ-Y2105L-R-P | 24VDC/220VACRS-232 | |||
| TQ-Y2105L-RA-P | 4-20mA/0-5V/0-10V |
Frequently Asked Questions
What are the typical applications of the MK-Y2105L?
Bench and process weighing with set-point control, plus integration into industrial automation, dosing and data-collection systems.
Which indicator, transmitter or system works with the MK-Y2105L?
It outputs a standard mV/V strain signal, so it connects to most weighing indicators and transmitters — including those in our Sensor Accessories range.
