Overview
The MK-Y2103 is a weighing fixed-value controller that integrates weight display, quantitative control and signal transmission in one industrial instrument. It combines high measurement accuracy with strong resistance to interference, and remains simple to operate despite its broad control functions.
Key Features
- Display, control and transmission in one unit
- High weighing accuracy
- Strong immunity to interference
- Simple operation
- Aluminum alloy elastic element for durability and corrosion resistance
- Standard output 4~20mA (or change to 0~5V), compatible with common indicators
Applications
Used on weighing and fixed-value control tasks where the weight signal must be displayed, regulated against a target value and retransmitted to other equipment.
| Technical Parameters | |||
|---|---|---|---|
| Display | 6Pcs Digital tube, 8Pcs LED Indicator Light | Keyboard | 5 Pcs membrane buttons |
| Appearance material | Aluminum alloy | Sensor excitation voltage | 5V DC (up to 8 pcs of 350Ω sensors) |
| Standard I/O Port configuration | Standard configuration with 4-channel output (Internal 4 pairs of relay contacts) | Quantity of process storage | 10 pcs |
| Serial port | Default RS485 (changeable to RS232) | Analog output | 4~20mA (or change to 0~5V) |
| A/D resolution rates | 2,000,000 | A/D conversion rates | 6.25~200Hz |
| Instrument power supply | 85~265VAC 50Hz ±2% | Dimension (L x W x D) | 90x42x130mm, panel 110x60mm |
| Operating temperature range | -20~60°C, relative humidity: 10%~85%, non-condensing | Storage temperature range | -40~80°C, relative humidity: 10%~85%, non-condensing |
Frequently Asked Questions
What are the typical applications of the MK-Y2103?
Used on weighing and fixed-value control tasks where the weight signal must be displayed, regulated against a target value and retransmitted to other equipment.
Which indicator, transmitter or system works with the MK-Y2103?
It outputs a standard mV/V strain signal, so it connects to most weighing indicators and transmitters — including those in our Sensor Accessories range.
